6 mm. Tapping Machine

Tapping Machine Capacity 6 mm.
Drilling Capacity 3 mm.
Spindle Travel/Table travel (6 mm.) 60 mm.
Distance Spindle to Column 80 mm.
Distance between chuck to base 190 mm.
Distance between chuck to work table movable
Size of base Plate-L x B 370 x 250 mm.
Size of Work Table-L x B 150 x 150 mm.
Diameter of Column 47 mm.
V-Belt (Inside) -
V-Belt for Motor (Outside) A-36
No. of Spindle Speeds 3
Forwards Speeds Range 480/750/1400
Reverse Speeds Range 480/750/1401
Motor Single phase or three phase 0.25 H.P.
  1440 R.P.M.
Overall Height 650 mm.
Overall Width 270 mm.
Overall front to back 540 mm.
Weight approx 50 Kg.
